Track Plan Finished

• well at least enough to start some track laying!! I am sure I will keep making changes.

After several hundred iterations - seriously - the track plan is complete enough to start some track laying - I have made a number of revisions to the station area again to better align it with the scale drawing.

The jpeg below shows the track plan overlayed on the scale drawing as a test to see if it is good enough.

As I said earlier the comparison is slightly false in that I have had to squash the scale drawing to make it fit in a reasonable length - that changes the aspect ratio of it rather - you can't shrink it in both directions as the platform widths (especially on the bay platforms) become untenable.
